It adopts a vertical, segmented structure and a non-self-priming vertical multi-stage centrifugal pump with an ordinary motor. It can transport all kinds of water from faucet water to industrial liquids. Completely different media are appropriate for different temperature, circulate and strain ranges, and likewise suitable for transporting mildly corrosive liquids.
cdlf vertical mild multi-stage centrifugal pump motor shaft and pump shaft are immediately linked with a coupling. The tie rod is used to connect the outer cylinder with a nut. The move part is fastened between the bracket and the water inlet and outlet. . The suction port and discharge port of the pump are designed to form a line at the bottom, and the best hydraulic mannequin is adopted. The pump inlet and outlet are on the same straight line at the bottom of the pump. The outer cylinder of the vertical stainless steel multi-stage centrifugal pump is manufactured from stainless steel and has a lovely appearance. The axial force of the pump is solved by a hydraulic balance method, and the residual axial force is borne by a ball bearing, so it runs smoothly, with low noise, small footprint, and handy decoration. It is particularly suitable for the parallel use of multiple pumps in excessive-rise buildings to scale back the facility of a single pump unit and simplify the digital management tools. It is suitable for hearth fighting, home water provide, air conditioning unit circulation, cooling water delivery, etc. of excessive- and low-rise buildings, residential buildings, hospitals, motels, department shops, office buildings, and many others.
CDLF2, 4 light vertical multistage pump structure diagram
CDLF32, 45, 64, ninety light vertical multistage centrifugal pump structure diagram
1. The use of excellent hydraulic fashions and advanced manufacturing know-how vastly improves the performance and repair life of the pump.
2. As a result of the shaft seal adopts mechanical seal made of hard alloy and fluororubber, it could actually enhance the reliability of pump operation and the temperature of the conveying medium.
3. The overflow part of the pump is stamped and welded by stainless steel plates, making the pump appropriate for mildly corrosive media.
4. The general structure is compact, small in measurement, mild in weight, low in noise, significant in vitality saving, and handy for upkeep.
5. The water inlet and outlet of the pump are located on the same horizontal line of the pump seat, which might be directly used in the pipeline.
7. Intelligent protectors may be equipped in keeping with person needs to successfully protect the pump from dry working, part loss, and overload.
